deegee XFH IP65 Xenon Strobe Double Flash Beacon 11J 115Vac White Base 225mm x 175mm dia. Red
This industrial, vehicle, and security-focused high-top xenon strobe offers an ABS base and polycarbonate dome lens, available in White (standard) or Black, with Red, Amber, Green, Blue, or Clear lens options. Onboard switches allow for the selection of four different flash rates. The device is available in 11 Joule and 24 Joule models, and works with 12Vuc, 24Vuc, 115Vac, or 230Vac power sources (uc = ac or dc), and can be configured for either Double-flash or Single-flash signalling.
Additional information
| Weight (kg) | 1.335 |
|---|---|
| Nominal Supply Voltage (V) | 115 |
| Voltage Min (V) | 98 |
| Voltage Max (V) | 132 |
| Supply Type | AC |
| Lens Colour | Red |
| Signal Colour | Red |
| Base Colour | White |
| Height (mm) | 225 |
| Diameter (mm) | 175 |
| Size (mm) | 225 x 175 dia. |
| IP Rating | IP65 |
| GTIN | 5060995743257 |
| Mounting method | Surface mounting |
| User Selectable Functions | 4 Flash Rates |
| Flash Energy (J) | 11 |
| Nominal Current Draw (A) | 0.16 |
| Light Source | Xenon |
| Luminous Intensity (cd) | 45 |
| Order Unit | 1 |
| MOQ | 1 |
| Quantity Interval | 1 |
| Status | Active |
| Commodity Code | 85319000 |
| Fuse (A) | 0.5 |
| Fuse Type | TD |
| Fuse (Internal or External) | Internal |
| Country of origin | GB |
| RoHS | RoHS3 (EU DIRECTIVE 2015/863) compliant |
| RoHS Last Verified Date | 8th August 2024 |
| SVHC | No SVHC present |
| SVHC Candidate List Date | 27th June 2024 |
| Factory Set Flashing Frequency (FPM) | 60 |
| Number of Flash Functions | 4 |
| Temperature Limits (C) | -20 to +55 |
| Base Material | ABS |
| Lens Material | Polycarbonate |
