deegee XFG IP68 Xenon Strobe Single Flash Beacon 12-70Vuc White Base 220mm x 256mm dia. Amber
This large, sturdy xenon strobe visual warning device has a polycarbonate base and dome lens, available in Red, Amber, Green, Blue, or Clear. The onboard switches allow installers to select from four flash rates. The 11 Joule models work with 12Vuc, 24Vuc, 115Vac, or 230Vac supplies (uc = ac or dc) and can be configured with either a Double-flash (default) or Single-flash signaling pattern. The beacon is provided as a complete unit with the base assembly and a coloured dome lens. Additionally, 5 Joule models are available for use with 10-100Vdc, 20-70Vac, or 100-130Vdc power supplies.
Additional information
| Nominal Supply Voltage (V) | 12-70 |
|---|---|
| Voltage Min (V) | 11 |
| Voltage Max (V) | 70 |
| Supply Type | UC |
| Lens Colour | Amber |
| Signal Colour | Amber |
| Base Colour | White |
| Height (mm) | 220 |
| Diameter (mm) | 256 |
| Size (mm) | 220 x 256 dia. |
| IP Rating | IP68 |
| Mounting method | Surface mounting |
| User Selectable Functions | 4 Flash Rates |
| Flash Energy (J) | 5 |
| Nominal Current Draw (A) | 0.35 |
| Light Source | Xenon |
| Order Unit | 1 |
| MOQ | 1 |
| Quantity Interval | 1 |
| Status | Active |
| Commodity Code | 85318070 |
| Factory Set Flashing Frequency (FPM) | 60 |
| Number of Flash Functions | 4 |
| Temperature Limits (C) | -20 to +55 |
| Base Material | Polycarbonate |
| Lens Material | Polycarbonate |
| GTIN | 5056711300415 |
| Luminous Intensity (cd) | 75 |
| Fuse (A) | 1 |
| Fuse Type | TD |
| Fuse (Internal or External) | Internal |
| Country of origin | GB |
| RoHS | RoHS3 (EU DIRECTIVE 2015/863) compliant |
| RoHS Last Verified Date | 8th August 2024 |
| SVHC | No SVHC present |
| SVHC Candidate List Date | 27th June 2024 |
| Weight (kg) | 1.621 |
