deegee XFF IP65 Xenon Strobe Single Flash Beacon 12-70Vuc 155mm x 155mm x 192mm Green
This resilient xenon beacon with a glass lens is made from AISI316 stainless steel, designed with chemical-resistant seals and stainless steel fixings. It’s built for harsh conditions like paper manufacturing, where acid-wash cleaning is common. The beacon includes a clear glass outer lens with polycarbonate lenses available in Red, Amber, Green, Blue, Yellow, or Clear. The onboard switches allow the installer to choose from four flash rates. The 11 Joule versions are compatible with 12Vuc, 24Vuc, 115Vac, or 230Vac supplies (uc = ac or dc) and are available with Double-flash or Single-flash signalling. The unit is supplied fully boxed, with 5 Joule models available for use with 10-100Vdc (20-70Vac) and 100-130Vdc supplies.
Additional information
| Weight (kg) | 3.4 |
|---|---|
| Nominal Supply Voltage (V) | 12-70 |
| Voltage Min (V) | 11 |
| Voltage Max (V) | 70 |
| Supply Type | UC |
| Lens Colour | Green |
| Signal Colour | Green |
| Length (mm) | 155 |
| Width (mm) | 155 |
| Height (mm) | 192 |
| Size (mm) | 155 x 155 x 192 |
| IP Rating | IP65 |
| GTIN | 5060995742465 |
| Mounting method | Surface mounting |
| User Selectable Functions | 4 Flash Rates |
| Flash Energy (J) | 5 |
| Nominal Current Draw (A) | 0.35 |
| Light Source | Xenon |
| Luminous Intensity (cd) | 30 |
| Order Unit | 1 |
| MOQ | 1 |
| Quantity Interval | 1 |
| Status | Active |
| Commodity Code | 85319000 |
| Fuse (A) | 1 |
| Fuse Type | TD |
| Fuse (Internal or External) | Internal |
| Country of origin | GB |
| RoHS | RoHS3 (EU DIRECTIVE 2015/863) compliant |
| RoHS Last Verified Date | 8th August 2024 |
| SVHC | No SVHC present |
| SVHC Candidate List Date | 27th June 2024 |
| Factory Set Flashing Frequency (FPM) | 60 |
| Number of Flash Functions | 4 |
| CE Approved | Yes |
| Temperature Limits (C) | -20 to +55 |
| Base Material | Stainless Steel |
| Lens Material | Glass |
