deegee PSK IP65 Pulsed LED Beacon 24Vdc White Base 185mm x 165mm dia. Clear
Our Pulsed LED Beacon Lamps utilise latest technology LED’s to provide a generally low power long life visual warning signal. Multi-function Rotating/Pulsed/Static LED Beacon with 8 operating modes. Static – non-flashing, Standard Pulse – 120fpm (2Hz), Slow Pulse – 60fpm (1Hz), Fast Pulse – 240fpm (4Hz), Triple Flash – Three flash pulses repating twice/second, Random Flash – Chaotic pulses repeating once/second, Strobe – 1 pulse per second (1Hz), Revolving (Simulated Rotating) – 120rpm
Additional information
| Weight (kg) | 0.682 |
|---|---|
| Nominal Supply Voltage (V) | 24 |
| Voltage Min (V) | 21 |
| Voltage Max (V) | 27 |
| Supply Type | DC |
| Lens Colour | Clear |
| Signal Colour | Clear |
| Base Colour | White |
| Height (mm) | 185 |
| Diameter (mm) | 165 |
| Size (mm) | 185mm x 165mm dia. |
| IP Rating | IP65 |
| Mounting method | Surface mounting |
| User Selectable Functions | 8-Function |
| Nominal Current Draw (A) | 0.108 |
| Light Source | LED |
| Luminous Intensity (cd) | 107 |
| Number of Flash Functions | 8 |
| CE Approved | Yes |
| Temperature Limits (C) | -20 to +55 |
| Base Material | ABS |
| Lens Material | Polycarbonate |
| Fuse (A) | 1 |
| Fuse Type | TD |
| Fuse (Internal or External) | Internal |
| Order Unit | 1 |
| MOQ | 1 |
| Quantity Interval | 1 |
| Status | Active |
| Commodity Code | 85318070 |
| GTIN | 5056711302556 |
| Marketing Bullet 1 | Mounting bracket available |
| Marketing Bullet 2 | Can be mounted in any orientation |
| Marketing Bullet 3 | Continuously rated |
| Marketing Bullet 4 | Incorporates an extra bright 120 wide-angle LED array |
| Marketing Bullet 5 | 360° light output around the vertical axis |
| Country of origin | GB |
| RoHS | RoHS3 (EU DIRECTIVE 2015/863) compliant |
| RoHS Last Verified Date | 8th August 2024 |
| SVHC | No SVHC present |
| SVHC Candidate List Date | 27th June 2024 |
